TK No. 30 Cleat Bender

---

 $1,150.00

   Quickly forms uniform drive cleat edges on rectangular duct with no requiredsetupp or adjustment. The upper handle forms the clea,t and the lower handle opens the work space for easy removal of the metal.  Optional Stand for $195.

• Weight: 126 lbs
• Dimensions: 42 x 16 x 20 in
• Capacity: 20 Ga Mild Steel
• Bend Length: 30″
• Cleat Depth: .500″.

 $7,450.00

 The No. 30 Power Cleat Bender also has an exclusive failsafe system built into its bending mechanism. This system uses a torque-limiting clutch to ensure the machine cannot be damaged during fabrication. The failsafe system is unobtrusive during normal operation, and can easily be reset with a switch under the work table surface. This means less downtime due to operator error, fewer machine repairs, and more time spent making the duct work you need.

• Material Capacity: 22-gauge mild steel
• Max. Material Width: 30"
• Working Surface Height: 31"
• Working Surface Depth: 36"
• Motor: 1 HP, 110 Volt, single phase 60 HZ
• Dimensions: 42" x 42" x 44"
• Weight: 650 lbs

 $12,500.00

   The Tin Knocker 3618 Power Cleat Bender is a heavy-duty, air-powered machine, designed for high-volume and high-speed production. Built for accuracy, repeatability, and long-term durability, it forms cleats on material up to 36″ wide and 18-gauge thick. The 3618 Power Cleat Bender is engineered to deliver faster cycling at maximum power—cutting cleat-forming time by nearly 50%. Ideal for demanding fabrication environments, this machine provides reliable performance, day after day.

 $1,150.00

Bench mounted, this machine comes ready for service. Consistent bends are a certainty due to the two-way trunnion keeping the bending apron in position at the origin of the bend. Adjusts for 1/4″ to 7/8″ bends (6.35mm – 22.2mm).

Optional Stand for $195

• Weight: 96 lbs.
• Dimensions: 40" x 12" x 10"
• Capacity: 20 Ga. Mild Steel (Galvanized) x 60″
• Bend Length: 24″
• Dimensions: Shims are required for 28 Ga and lighter material

 $5,850.00

The Tin Knocker Button Punch Cheek bender is a versatile machine that allows operators to create 3 different types of flanges for use in the fabrication of fittings, with a single piece of hardened tooling. The button punch cheek bender is hydraulically-driven, and easy to operate via foot pedal, improving the efficiency of any shop.

The button punch cheek bender allows the operator to create 3 types of flanges:
• ½” right angle flange with button punch
• ½” right angle Pittsburgh flange
• ¼” right angle Pittsburgh flange
